SG BODY REFLECTOR BASE - PASSIVE UNIT • SG BODY REFLECTOR MUTING - PASSIVE UNIT
SG BODY REFLECTOR BASE WITH T MUTING ARMS - ACTIVE SIDE
MODEL
L1 [mm]
L2 [mm]
SG4-RDB2
580,5
520,5
SG4-RDB2L
580,5
520,5
SG4-RDB2T
580,5
520,5
SG4-RDB3
880,5
820,5
SG4-RDB3L
880,5
820,5
SG4-RDB3T
880,5
820,5
SG4-RDB4-090
980,5
920,5
SG4-RDB4-120
1280,5
1220,5
SAFETY SENSORS
�
SG BODY REFLECTOR BASE
SG BODY REFLECTOR MUTING
