CHARACTERISTICS
S5
SL5
S300
GENERAL DATA
Format
M18 Tubular
M18 Tubular
Rectangular
Light Emission
Infrared LED 880 nm
Class 1 Red laser (650 nm)
Infrared LED 880 nm
Type (EN61496-1)
2/4 depending on model
4
2/4 depending on model
Effective Aperture Angle (EN61496-2)
-/+ 2.5° for Type 4 models
-/+ 5° for Type 2 models
Operating distance
0 … 8 m
0 … 40 m
0 … 50 m (S300…ST2)
9 … 40 m (S300…ST4)
ELECTRICAL DATA
Power supply (Vdc)
24 Vdc ± 15%
Outputs
PNP (short circuit protection)
Output current
100 mA max.
Response time
1 ms max.
MECHANICAL AND ENVIRONMENTAL DATA
Operating temperature
-25 … 55°C
-10 … 50 °C
-40 … 55 °C
Mechanical protection (EN 60529)
IP 67
SG-BWS-T4
SG-BWS-T4-MT
GENERAL DATA
PL (EN ISO 13849-1)
e
SIL (IEC 61508)
3
ELECTRICAL DATA
Power supply
24 Vdc -15/+10%
Inputs
PNP Outputs from S5/SL5/S300
4
4
OSSDs couples from SLC
---
2
Muting inputs
---
4
Test, Reset, Override, EDM,
Muting enable, Auto/Man Selector
3
9
Outputs
Safety outputs
2 PNP
2 NO
Muting lamps
---
2
Test outputs
4
4
Response time
A
29 ms
39 ms
MECHANICAL AND ENVIRONMENTAL DATA
Operating temperature
0 … +55°C
Humidity
15 … 95 % (no condensation)
Mechanical protection
IP20
FUNCTIONS
B
Automatic/Manual reset
External Device Monitoring
---
L/T Muting
---
Double muting
---
Muting Enable
---
Muting timeout
---
Override
COMPATIBILITY
Single beam photocells
S5/SL5/S300
Safety light curtains
---
All DATALOGIC SLC
NOTES
A
includes response time of photocells
B
Functions setting is done through DIP switches in SG-BWS-T4-MT and through wiring in SG-BWS-T4
