45
ACCESSORIES
SG BODY REFLECTOR BASE
[ SG4-RBx-xxx-OO-E ] + [SG4-RDBx ]
SG BODY REFLECTOR MUTING
[ SG4-RBx-xxx-OO-W ] + [SG4-RDBx ]
[SG4-RBxL/T-xxx-OO-W] + [SG4-RDBxL/T ]
BRACKETS
Included with the light curtain
None
Standard angled brackets (4 pcs)
ST-K4STD-SG-BODY BIG
Rear fixing bracket mounting (4 pcs)
ST-K4REAR-SG BODY BIG
Rotating brackets (4 pcs)
ST-K4ROT-SG BODY BIG
Antivibration support (4 pcs/6 pcs)
B
ST-K4AV
ST-K6AV
Plastic brackets (4 pcs/6 pcs)
B
ST-KP4MP
ST-KP6MP
PROTECTION TUBES, STANDS
IP67/IP69K Tubes
---
Protective Stands
SG-PSB series
A
Stand Plate for SG-PSB
SG-P
Protective Stands Mounting Brackets (4 pcs/6 pcs)
B
ST-PS4-SG BODY
ST-PS6-SG BODY
Floor columns
SE-S Series
SAFETY UNITS
Safety Unit
SE-SR2
EDM Relay Box
C
CS ME-03VU24-Y14
Safety control unit for single beams and SLC
SG-BWS-T4-MT
ALIGNMENT TOOL
LASER Pointer
SG-LP
ACCESSORIES FOR MUTING
Muting arms, brackets and cables
---
See page 76
Muting Connection box
C
---
SG-SRT-1 or SG-SRT-2
External muting lamps
---
LMS Series
NOTES
A
Not possible with T or L muting arms mounted
B
Use 6 brackets for light curtains with length ≥ 1200 mm
C
When using EDM Relay Box or Muting connection boxes, connect EDM input, and be sure EDM function is active on the safety light curtain
SAFETY SENSORS
�
SG BODY REFLECTOR BASE
SG BODY REFLECTOR MUTING
