CHARACTERISTICS
SG BODY REFLECTOR BASE
[ SG4-RBx-xxx-OO-E ] + [SG4-RDBx ]
SG BODY REFLECTOR MUTING
[ SG4-RBx-xxx-OO-W ] + [SG4-RDBx ]
[SG4-RBxL/T-xxx-OO-W] + [SG4-RDBxL/T ]
GENERAL DATA
Type (EN61496-1)
4
PL (EN ISO 13849-1)
e
SIL (IEC 61508)
3
Resolution
319,75 mm (4 beams)
419,75 mm (3 and 4 beams)
519,75 mm (2 beams)
Protected height
500 mm (2 beams)
800 mm (3 beams)
900 mm or 1200 (4 beams)
Operating distance
0.5 … 8 m
0.5 … 6.5 m (for SG4-RB4-090-OO-E)
0.5 … 8 m (for SG4-RBx-xxx-OO-W)
0.5 … 6.5 m (for SG4-RB4-090-OO-W)
0.5 … 3 m (for SG4-RBxL/T-OO-W)
Retroreflective muting arms
operating distance
(included in T and L models)
0.5 … 3 m
Emitter-Receiver muting arms
operating distance
(not included)
---
0.5 … 7 m
ELECTRICAL DATA
Power supply (Vdd)
24 Vdc ± 20%
Outputs
2 PNP
Output current
0.5 A max/each output
Capacitive load
2,2 uF max at 25°C
Response time
11 ... 12 ms depending on model
A
Cables length (for power supply)
70 m max.
MECHANICAL AND ENVIRONMENTAL DATA
Operating temperature
0 …+55 °C
Humidity
15 … 95 % (no condensation)
Mechanical protection
IP 65 (EN 60529)
FUNCTIONS
Manual/Automatic restart
External Device Monitoring (EDM)
Coding selection with DIP-SW
---
T-Muting/L-Muting
Integrated muting lamp
---
Muting timeout: 10 min. or ∞
Integrated muting lamp
---
Override
---
Muting enable input
---
Override status output
---
Muting filter
---
Externa muting lamp output
NOTES
A
For detailed informations refer to related Product Datasheet or Manual
