CHARACTERISTICS
SG2 MUTING
[ SG2-30-xxx-OO-W ]
SG4 EXTENDED
[ SG4-xx-xxx-OO-P ]
GENERAL DATA
Type (EN61496-1)
2
4
PL (EN ISO 13849-1)
d
e
SIL (IEC 61508)
2
3
Resolution
30 mm
14, 30 mm
Protected height
300 … 1800 mm (with 150 mm steps)
Operating distance
0.2 … 20 m
0.2 … 7 m (14 mm resolution)
0.2 … 20 m (30 mm resolution)
Dead Zone
No dead zone
Cascade connection
---
Up to 3 units
ELECTRICAL DATA
Power supply (Vdd)
24 Vdc ± 20
Outputs
2 PNP, with short circuit protection
2 PNP
Output current
0.5 A max/each output
Capacitive load
2.2 uF @ 24Vdc max
Response time
13 … 22 ms depending on model
A
13 … 33 ms depending on model
A
Cables length (for power supply)
50 m max
MECHANICAL AND ENVIRONMENTAL DATA
Operating temperature
0 …+50 °C
Humidity
15 … 95 % (no condensation)
Mechanical protection
IP 65 (EN 60529)
FUNCTIONS
Test input
Manual/Automatic Restart
External Device Monitoring (EDM)
---
Anti-interference coding
Range reduction
T Muting/L Muting
---
Partial Muting
---
Filter on muting signals
Muting dependent Override
---
Floating Blanking
---
Fixed Blanking
Max. Number of Blanking Areas
---
5
---
Reduced Resolution
NOTES
A
The response time depends on model; when a cascaded system is used, depends also on the number of units connected.
For detailed informations refer to related Product Datasheet or Manual.
IMPORTANT NOTES:
1) The use of any type of blanking is not compatible with the use of Muting and Muting dependent Override.
2) In order to use Muting or Blanking with SG4 EXTENDED, the correct pigtail cable must be used (see accessories table)
