36
SG
2
-
B2
-
050
-OO-
E
SG4-40-
060
-OO-E
Robust housing for harsh environments
Long operating range for perimeter control
Rapid solution for access control with muting
Easy installation and alignment
• 2, 3, 4 beams for body protection
• 40 mm resolution for arm protection and presence detection
• Controlled heights 500, 800, 900 and 1200 mm
• Long operating distance: up to 60 m
• Simple configuration through DIP switches
• Integrated muting lamp (only muting models)
• Anti-interference coding
• External muting enable signal
• Edged or triggered muting dependent override
SG BODY BIG BASE
SG BODY BIG MUTING
Finger
Hand
Arm
Body
Type 2
•
Type 4
•
•
TYPE
2
Type 2
4
Type 4
BEAMS AND RANGE
B2
2 Beams
B3
3 Beams
B4
4 Beams
BSR2 2 Beams Short Range (only type 4)
BSR3 3 Beams Short Range (only type 4)
BSR4 4 Beams Short Range (only type 4)
BLR2 2 Beams Long Range (only type 4)
BLR3 3 Beams Long Range (only type 4)
BLR4 4 Beams Long Range (only type 4)
VERSION
E
Base: without
muting function
W-C
Muting: with integrated
muting function
MONITORED HEIGHT
050 500 mm (2 beams)
080 800 mm (3 beams)
090 900 mm (4beams)
120 1200 mm (4 beams)
MONITORED HEIGHT
060
660 mm
090
960 mm
120
1260 mm
SAFETY SENSORS
