SG BODY COMPACT BASE
SG BODY COMPACT MUTING
SAFETY SENSORS
�
AVAILABLE MODELS AND ORDER CODES
CABLE ORDER CODES
SG2 BODY COMPACT BASE
[ SG2-Sx-xxx-PP-E ]
Order code
SG4 BODY COMPACT BASE
[ SG4-Sx-xxx-PP-E ]
Order code
BODY
PROTECTION
WITHOUT
MUTING
SG2-S2-050-PP-E
957851000
SG4-S2-050-PP-E
957851040
SG2-S3-080-PP-E
957851010
SG4-S3-080-PP-E
957851050
SG2-S4-090-PP-E
957851020
SG4-S4-090-PP-E
957851060
SG2-S4-120-PP-E
957851030
SG4-S4-120-PP-E
957851070
BODY PROTECTION WITH INTEGRATED
MUTING
WITHOUT
MUTING ARMS
SG2 BODY COMPACT MUTING
[ SG2-S/L/Tx-xxx-PP-W ]
Order code
SG4 BODY COMPACT MUTING
[ SG4-S/L/Tx-xxx-PP-W ]
Order code
SG2-S2-050-PP-W
957851080
SG4-S2-050-PP-W
957851160
SG2-S3-080-PP-W
957851090
SG4-S3-080-PP-W
957851170
SG2-S4-090-PP-W
957851100
SG4-S4-090-PP-W
957851180
SG2-S4-120-PP-W
957851110
SG4-S4-120-PP-W
957851190
WITH L
MUTING
ARMS
SG2-L2-050-PP-W
957851120
SG4-L2-050-PP-W
957851200
SG2-L3-080-PP-W
957851130
SG4-L3-080-PP-W
957851210
WITH T
MUTING
ARMS
SG2-T2-050-PP-W
957851140
SG4-T2-050-PP-W
957851220
SG2-T3-080-PP-W
957851150
SG4-T3-080-PP-W
957851230
TRANSMITTER CABLE
(MAIN CONNECTOR)
LENGTH (m)
CONNECTOR
ORDER CODE
SG BODY COMPACT BASE
[ SG2-Sx-xxx-PP-E ]
[ SG4-Sx-xxx-PP-E ]
CV-A1-22-B-03
3
Axial
95ACC1480
CV-A1-22-B-05
5
Axial
95ACC1490
CV-A1-22-B-10
10
Axial
95ACC1500
CV-A1-22-B-15
15
Axial
95ACC2070
CV-A1-22-B-25
25
Axial
95ACC2090
SG BODY COMPACT MUTING
[ SG2-S/L/Tx-xxx-PP-W ]
[ SG4-S/L/Tx-xxx-PP-W ]
CV-A2-22-B-03
3
Radial
95ACC1540
CV-A2-22-B-05
5
Radial
95ACC1550
CV-A2-22-B-10
10
Radial
95ACC1560
RECEIVER CABLE
(MAIN CONNECTOR)
LENGTH (m)
CONNECTOR
ORDER CODE
SG BODY COMPACT BASE
[ SG2-Sx-xxx-PP-E ]
[ SG4-Sx-xxx-PP-E ]
CV-A1-26-B-03
3
Axial
95ACC1510
CV-A1-26-B-05
5
Axial
95ACC1520
CV-A1-26-B-10
10
Axial
95ACC1530
CV-A1-26-B-15
15
Axial
95ACC2080
CV-A1-26-B-25
25
Axial
95ACC2100
SG BODY COMPACT MUTING
[ SG2-S/L/Tx-xxx-PP-W ]
[ SG4-S/L/Tx-xxx-PP-W ]
CV-A2-26-B-03
3
Radial
95ACC1600
CV-A2-26-B-05
5
Radial
95ACC1610
CV-A2-26-B-10
10
Radial
95ACC1620
TRANSMITTER CABLE
(SECONDARY CONNECTOR)
LENGTH (m)
CONNECTOR
ORDER CODE
SG BODY COMPACT MUTING (LINEAR)
[ SG2-Sx-xxx-PP-W ]
[ SG4-Sx-xxx-PP-W ]
CS-A1-03-U-03
3
Axial
95ASE1170
CS-A1-03-U-05
5
Axial
95ASE1180
CS-A1-03-U-10
10
Axial
95ASE1190
CS-A1-03-U-15
15
Axial
95ASE1200
CS-A1-03-U-25
25
Axial
95ASE1210
IMPORTANT NOTES
1) The cables for the secondary connector of SG BODY COMPACT MUTING T and L are provided within the package
2) In order to install SG4 EXTENDED or SG2 MUTING in place of SE2 BODY and SE4 BODY safety light curtains, without changing any wiring, it can be used the cable CV-Y3-
36-B-002 (order n. 95A252900) for receiver. All functions of SE will be available, except Override. SG BODY COMPACT MUTING has integrated muting lamp, therefore any external
muting lamp connected that was connected to SE light curtain, will not lit. Ensure that the integrated muting lamp of SG BODY COMPACT MUTING will be visible.
