RG_Safety_EN - page 32

32
179
643,5
700
164 164 89,5
35
44,1
40,9
349,5
378 44,1
164
35 40,9
DIMENSIONS (mm)
Model L1 (mm) L2 (mm) A (mm) B (mm) C (mm)
SGx-S/L/Tx-050-PP-E 662 538.4 120-260 653 700
SGx-S/L/Tx-080-PP-E 962 838.4 120-260 953 1000
SGx-S/L/Tx-090-PP-E 1062.5 938.4 120-260 1053 1100
SGx-S/L/Tx-120-PP-E 1362.5 1238.4 120-260 1353 1400
SG BODY COMPACT BASE
SG BODY COMPACT MUTING SAFETY SENSORS �
