ACCESSORIES
SG2 BODY COMPACT BASE
SG4 BODY COMPACT BASE
[ SG2/4-Sx-xxx-PP-E ]
SG2 BODY COMPACT MUTING
SG4 BODY COMPACT MUTING
[ SG2/4-S/L/Tx-xxx-PP-W ]
BRACKETS
Standard angled brackets (4 pcs)
A
ST-KSTD (outfit)
Rotating brackets (4 pcs)
ST-K4ROT-SG BODY COMPACT
Antivibration support (4 pcs/6 pcs)
C
ST-K4AV
ST-K6AV
Orientable support (4 pcs/6 pcs)
C
ST-K4OR
ST-K6OR
Plastic brackets (4 pcs/6 pcs)
C
ST-KP4MP
ST-KP6MP
PROTECTION TUBES AND STANDS
IP67/IP69K Tubes
---
Protective Stands
SG-PSB series
B
Stand Plate for SG-PSB
SG-P
Protective Stands Mounting Brackets (4 pcs/6 pcs)
C
ST-PS4-SG-SE
ST-PS6-SG-SE
Floor Columns
SE-S Series
MIRRORS
Protective stands with single mirrors
SG-PSM series
Deviating Mirrors mounting kit for SG-PSB
ST-PS-DM
Deviating Mirrors
SG-DM series
Mirror Mounting Bracket
ST-DM
SAFETY UNITS
Safety Unit
SE-SR2
EDM Relay Box
D
CS ME-03VU24-Y14
Safety control unit for single beams and SLC
SG-BWS-T4-MT
ALIGNMENT TOOL
LASER Pointer
SG-LP
ACCESSORIES FOR MUTING
Muting arms, brackets and cables
---
See page 77
Muting connection box
---
SG-SRT-1
D
External muting lamps
---
LMS series
NOTES
A
1200 mm models are provided with 6 pcs standard brackets
B
Not possible with T or L muting arms mounted
C
Use 6 brackets for light curtains with length ≥ 1200 mm
D
When using EDM Relay Box or Muting connection box, connect EDM input, and be sure EDM function is active on the safety light curtain
SAFETY SENSORS
�
SG BODY COMPACT BASE
SG BODY COMPACT MUTING
