SG2 BASE
[ SG2-xx-xxx-OO-X ]
SG2 EXTENDED
[ SG2-xx-xxx-OO-E-C ]
SG4 BASE
[ SG4-xx-xxx-OO-E ]
EMITTER
RECEIVER
NOTES
For manual restart, connect Pin 8 with Pin 6
For automatic restart, connect Pin 8 with Pin 5
To deactivate EDM function, connect Rx Pin 3 to 24Vdc on Receiver
SG2 BASE
[ SG2-xx-xxx-OO-X ]
SG2 EXTENDED
[ SG2-xx-xxx-OO-E-C ]
SG4 BASE
[ SG4-xx-xxx-OO-E ]
BRACKETS
Standard angled brackets
ST-KSTD (outfit for SG2 Base and SG4 Base)
Rotating brackets
ST-K4ROT (outfit for SG2 Extended)
Antivibration support (4 pcs/6 pcs)
C
ST-K4AV
ST-K6AV
Plastic brackets (4 pcs/6 pcs)
C
ST-KP4MP
ST-KP6MP
PROTECTION TUBES AND STANDS
IP67/IP69K Tubes
SG-IP69K series
Protective Stands
SG-PSB series
Stand Plate for SG-PSB
SG-P
Protective Stands Mounting Brackets
(4 pcs/6 pcs)
C
ST-PS4-SG-SE
ST-PS6-SG-SE
Floor Columns
SE-S Series
MIRRORS
Deviating Mirrors
SG-DM Series
Deviating Mirrors mounting kit for SG-PSB
ST-PS-DM
Mirror Mounting Bracket
ST-DM
SAFETY UNITS
Safety Unit
SE-SR2
EDM Relay Box
B
---
CS ME-03VU24-Y14
Safety control unit for single beams and SLC
SG-BWS-T4-MT
ALIGNMENT TOOL
LASER Pointer
SG-LP
NOTES
C
Use 6 brackets for light curtains with length ≥ 1200 mm
B
When using EDM Relay Box or Muting connection box, connect EDM input, and be sure EDM function is active on the safety light curtain
CONNECTIONS
ACCESSORIES
SG2 BASE
SG2 EXTENDED
SG4BASE
SAFETY SENSORS
�
