-Working and assembling lines
-Packaging machinery
-Light conveyors
APPLICATIONS
INCREMENTAL ENCODERS
ENC41
Basic Line
• Compact dimension Ø41mm
• Hollow or solid shaft
• Cost effective
• Light duty
MECHANICAL AND ENVIRONMENTAL SPECIFICATIONS
Case dimension
Ø 40.5 mm, depth 34 mm
Shaft dimension
Hollow or solid shaft Ø 6 mm
Shaft loading (axial and radial)
20 N max.
Shaft rotational speed
6000 rpm max.
Starting torque at 20 °C
≤ 0.3 Ncm (typ.)
Bearings life
10
9
min.
Weight
0.1 kg (3.5 oz) ca.
Case material
Fibre glass epoxy resin
Flange material
Aluminium anticorodal UNI EN AW-6082
Shaft material
Stainless steel non-magnetic UNI EN 4305
Bearings material
ABEC 5
Mechanical protection
IP64
Shock resistance
100g, 6 ms (MIL STD 202F)
Vibration resistance
10 g, 5-2000 Hz (MIL STD 202F)
Operating temperature
-25 to +85°C (-13 to 185°F)
Storage temperature
-25 to +85°C (-13 to 185°F), 98% R.H. non condensing
Note: specifications subject to changes without prior notice, please refer to the user manual received with the product for mounting, wiring and operation.
