EXTENDED LINE
ENC58
Power supply
5-30 Vdc
Resolution
up to 10000 pulse per revolution (PPR) and programmable mod.
Output signals
AB0 and /A/B/0
Output circuit
Smart Push-Pull & Line Driver
Connection
cable 1.5m or connector M12 or M23
Case diameter
Ø 58 mm
Case material
anticorodal aluminium, UNI EN AW-6082
Flange material
anticorodal aluminium, UNI EN AW-6082
Shaft material
stainless steel, non-magnetic - UNI EN 4305
Shaft type
hollow shaft
solid shaft
Shaft diameter
○
Ø 14 mm
○
Ø 15 mm
●
Ø 6 mm
●
Ø 10 mm
500 PPR/cable
ENC58-H14-0500-C15
ENC58-H15-0500-C15
ENC58-S06-0500-C15
ENC58-S10-0500-C15
1000 PPR/cable
ENC58-H14-1000-C15
ENC58-H15-1000-C15
ENC58-S06-1000-C15
ENC58-S10-1000-C15
1024 PPR/cable
ENC58-H14-1024-C15
ENC58-H15-1024-C15
ENC58-S06-1024-C15
ENC58-S10-1024-C15
2000 PPR/cable
ENC58-H14-2000-C15
ENC58-H15-2000-C15
ENC58-S06-2000-C15
ENC58-S10-2000-C15
2048 PPR/cable
ENC58-H14-2048-C15
ENC58-H15-2048-C15
ENC58-S06-2048-C15
ENC58-S10-2048-C15
2500 PPR/cable
ENC58-H14-2500-C15
ENC58-H15-2500-C15
ENC58-S06-2500-C15
ENC58-S10-2500-C15
5000 PPR/cable
ENC58-H14-5000-C15
ENC58-H15-5000-C15
ENC58-S06-5000-C15
ENC58-S10-5000-C15
10000 PPR/cable
ENC58-H14-10000-C15
ENC58-H15-10000-C15
ENC58-S06-10000-C15
ENC58-S10-10000-C15
500 PPR/M12
ENC58-H14-0500-M12
ENC58-H15-0500-M12
-
ENC58-S10-0500-M12
1000 PPR/M12
ENC58-H14-1000-M12
ENC58-H15-1000-M12
-
ENC58-S10-1000-M12
1024 PPR/M12
ENC58-H14-1024-M12
ENC58-H15-1024-M12
-
ENC58-S10-1024-M12
2000 PPR/M12
ENC58-H14-2000-M12
ENC58-H15-2000-M12
-
ENC58-S10-2000-M12
2048 PPR/M12
ENC58-H14-2048-M12
ENC58-H15-2048-M12
-
ENC58-S10-2048-M12
2500 PPR/M12
ENC58-H14-2500-M12
ENC58-H15-2500-M12
-
ENC58-S10-2500-M12
5000 PPR/M12
ENC58-H14-5000-M12
ENC58-H15-5000-M12
-
ENC58-S10-5000-M12
10000 PPR/M12
ENC58-H14-10000-M12
ENC58-H15-10000-M12
-
ENC58-S10-10000-M12
500 PPR/M23
ENC58-H14-0500-M23
ENC58-H15-0500-M23
ENC58-S06-0500-M23
ENC58-S10-0500-M23
1000 PPR/M23
ENC58-H14-1000-M23
ENC58-H15-1000-M23
ENC58-S06-1000-M23
ENC58-S10-1000-M23
1024 PPR/M23
ENC58-H14-1024-M23
ENC58-H15-1024-M23
ENC58-S06-1024-M23
ENC58-S10-1024-M23
2000 PPR/M23
ENC58-H14-2000-M23
ENC58-H15-2000-M23
ENC58-S06-2000-M23
ENC58-S10-2000-M23
2048 PPR/M23
ENC58-H14-2048-M23
ENC58-H15-2048-M23
ENC58-S06-2048-M23
ENC58-S10-2048-M23
2500 PPR/M23
ENC58-H14-2500-M23
ENC58-H15-2500-M23
ENC58-S06-2500-M23
ENC58-S10-2500-M23
5000 PPR/M23
ENC58-H14-5000-M23
ENC58-H15-5000-M23
ENC58-S06-5000-M23
ENC58-S10-5000-M23
10000 PPR/M23
ENC58-H14-10000-M23
ENC58-H15-10000-M23
ENC58-S06-10000-M23
ENC58-S10-10000-M23
PROG PPR/M23
ENC58-H14-PROG-M23
ENC58-H15-PROG-M23
-
ENC58-S10-PROG-M23
ENC
58
