INCREMENTAL ENCODERS
SOLID SHAFT MODELS
SHAFT CONNECTION RESOLUTION MODEL ORDER NO.
Solid shaft
● Ø6 mm
Cable 1.5m
500 PPR ENC58-S06-0500-C15 95B080140
1000 PPR ENC58-S06-1000-C15 95B080150
1024 PPR ENC58-S06-1024-C15 95B080160
2000 PPR ENC58-S06-2000-C15 95B080170
2048 PPR ENC58-S06-2048-C15 95B080180
2500 PPR ENC58-S06-2500-C15 95B081500
5000 PPR ENC58-S06-5000-C15 95B080190
10000 PPR ENC58-S06-10000-C15 95B080200
M23 conn.
500 PPR ENC58-S06-0500-M23 95B080210
1000 PPR ENC58-S06-1000-M23 95B080220
1024 PPR ENC58-S06-1024-M23 95B080230
2000 PPR ENC58-S06-2000-M23 95B080240
2048 PPR ENC58-S06-2048-M23 95B080250
2500 PPR ENC58-S06-2500-M23 95B081510
5000 PPR ENC58-S06-5000-M23 95B080260
10000 PPR ENC58-S06-10000-M23 95B080270
Solid shaft
● Ø10 mm
Cable 1.5m
500 PPR ENC58-S10-0500-C15 95B080280
1000 PPR ENC58-S10-1000-C15 95B080290
1024 PPR ENC58-S10-1024-C15 95B080300
2000 PPR ENC58-S10-2000-C15 95B080310
2048 PPR ENC58-S10-2048-C15 95B080320
2500 PPR ENC58-S10-2500-C15 95B081520
5000 PPR ENC58-S10-5000-C15 95B080330
10000 PPR ENC58-S10-10000-C15 95B080340
M12 conn.
500 PPR ENC58-S10-0500-M12 95B080430
1000 PPR ENC58-S10-1000-M12 95B080440
1024 PPR ENC58-S10-1024-M12 95B080450
2000 PPR ENC58-S10-2000-M12 95B080460
2048 PPR ENC58-S10-2048-M12 95B080470
2500 PPR ENC58-S10-2500-M12 95B081540
5000 PPR ENC58-S10-5000-M12 95B080480
10000 PPR ENC58-S10-10000-M12 95B080490
M23 conn.
500 PPR ENC58-S10-0500-M23 95B080350
1000 PPR ENC58-S10-1000-M23 95B080360
1024 PPR ENC58-S10-1024-M23 95B080370
2000 PPR ENC58-S10-2000-M23 95B080380
2048 PPR ENC58-S10-2048-M23 95B080390
2500 PPR ENC58-S10-2500-M23 95B081530
5000 PPR ENC58-S10-5000-M23 95B080400
10000 PPR ENC58-S10-10000-M23 95B080410
Programmable ENC58-S10-PROG-M23 95B080420
