66
NOTE: the dimensions (mm) are related to SG4 EXTENDED. For other models of light curtains, refer to their manual.
NOTE: the dimensions (mm) are related to SG4 EXTENDED. For other models of light curtains, refer to their manual.
Plastic angled brackets
MODEL
DESCRIPTION
ORDER NUMBER
ST-KP4MP
Fixing brackets (4 pcs kit)
95ASE1100
ST-KP6MP
Fixing brackets (6 pcs kit)
95ASE1110
COMPATIBILITY
SG2 BASE, SG4 BASE
SG2 EXTENDED, SG4 EXTENDED
SG2/4 BODY COMPACT
SG2 MUTING
SG2/4 BODY BIG
SG4 BODY REFLECTOR
SG4 LONG RANGE BASE.
NOTES
They can be used in combination with orientable (ST-K4OR/K6OR) or antivibration (ST-K4AV/K6AV) supports.
ACCESSORIES
�
BRACKETS
Angled mounting bracket + Anti-vibration support
Angled mounting bracket + Orientable support + Anti-vibration support
