ACCESSORIES
Accessories for muting
Some models of Safety Light Curtains series SG BODY COMPACT MUTING and SG BODY REFLECTOR MUTING are
provided with active/passive muting arms in the packaging, but it's also possible to add muting arms as accessories (if
the light curtain has integrated muting function).
Instead of using the active/passive arm couple, in which on side is an active sensor, and the other is a passive reflector,
in order to reach longer operating distance or to contrast the effect of environmental conditions, is possible to order also
“F/G” muting arm couples, composed by an emitter and a receiver arm.
IMPORTANT NOTICE: For safety reasons, L muting arms should be used only for openings through which goods must
exit from the dangerous area: for openings in which goods must enter the dangerous area, as well as for bi-directional
movements, use T muting arms.
Active/Passive Arms
Emitter/Receiver Arms
Muting Arms, Brackets, Cables
MODEL
DESCRIPTION
ORDER NUMBER
SG-L-ARMS V2
Active/Passive arms Couple for L muting
95ASE1861
SG-T-ARMS V2
Active/Passive arms Couple for T muting
95ASE1871
SG-AS-ARM V2
Active sensor single arm
95ASE1841
SG-PR-ARM V2
Passive reflector single arm
95ASE1851
SG-F1-G1-ARMS
Emitter/Receiver arms couple (first couple)
95ASE1880
SG-F2-G2-ARMS
Emitter/Receiver arms couple (second couple)
95ASE1890
