ACCESSORIES
�
SAFETY UNITS AND INTERFACES
SG-SRT1 and SG-SRT2 are interfaces provided with redundant forcibly guided relays, supplying a ready operator
interface to restart or override the Safety Light Curtain, and have muting indication.
Connection Boxes
SG-SRT1
SG-SRT2
ELECTRICAL DATA
Power supply
24 Vdc +/- 20%
Safe outputs
2 NO
Max. switchable voltage
250 Vac
Max. switchable current
2 A
FUNCTIONS
Reset mode
Automatic/Manual
Test
Reset
Restart
Override
---
Muting state indication
COMPATIBILITY
SG BODY COMPACT MUTING
SG BODY BIG MUTING
SG BODY REFLECTOR MUTING
SG BODY BIG MUTING
SG BODY REFLECTOR MUTING
NOTE
SG-SRT1 and SG-SRT2 provide internal or external EDM signal to the Safety Light Curtain: to operate safely, EDM monitoring function must be activated on the Safety Light
Curtain and correct wiring must be followed.
For further information refer to SG-SRT1/2 manual and the used Safety Light Curtain manual.
