77
Brackets and cables
Compatibility and Operating distances
MODEL
DESCRIPTION
ORDER NUMBER
SG-CB-B
Muting arms mounting bracket kit for BIG series
95ASE1920
SG-CB-C
Muting arms mounting bracket kit for COMPACT series
95ASE1930
CV-Y1-02-B-007
M12 4 pole T muting cable
95ACC2560
CV-L1-02-B-007
M12 4 pole L muting cable
95ACC2570
MUTING ARM
LIGHT CURTAIN
OPERATING DISTANCE
SG-L-ARMS V2
SG-T-ARMS V2
SG BODY COMPACT MUTING
SG2 MUTING
SG4 EXTENDED
0.5 … 3 m
SG-AS-ARM V2
SG-PR-ARM V2
SG BODY COMPACT MUTING
SG BODY REFLECTOR MUTING
SG2 MUTING
SG4 EXTENDED
SG4 BODY BIG MUTING SHORT RANGE
A
0.5 … 3 m
SG-F1-G1-ARMS
SG-F2-G2-ARMS
SG2 BODY BIG MUTING
SG4 BODY BIG MUTING SHORT RANGE
A
SG BODY COMPACT MUTING
0.5 … 7 m
NOTES
A
SG4 BODY MUTING LONG RANGE (whose operating range is 6 … 60 m) can't be used in combination with muting arms.
SG-AS-ARM V2
ACCESSORIES
�
ACCESSORIES FOR MUTING
