OPTIC FUNCTION
CONTROLLED HEIGHT & RESOLUTION OUTPUT & CONNECTION
SETTING
MODEL
ORDER No.
Measurement
light curtain
100 mm (res.: 7 mm)
Voltage Analog, PNP;
M12 Connector
5 pole (RX)
4 pole (TX)
n/a
DS1-LD-SR-010-JV
957701130
100 mm (res.: 4 mm)
DS1-LD-HR-010-JV
957701120
150 mm (res.: 7 mm)
DS1-LD-SR-015-JV
957701150
150 mm (res.: 4 mm)
DS1-LD-HR-015-JV
957701140
300 mm (res.: 7 mm)
DS1-LD-SR-030-JV
957701160
100 mm (res.: 7 mm)
Adjustment trimmer
DS1-LD-SR-010-PV
957701250
150 mm (res.: 7 mm)
DS1-LD-SR-015-PV
957701260
300 mm (res.: 7 mm)
DS1-LD-SR-030-PV
957701270
100 mm (res.: 7 mm)
n/a
DS1-SD-SR-010-JV
957701170
100 mm (res.: 4 mm)
DS1-SD-HR-010-JV
957701200
150 mm (res.: 7 mm)
DS1-SD-SR-015-JV
957701180
150 mm (res.: 4 mm)
DS1-SD-HR-015-JV
957701210
300 mm (res.: 7 mm)
DS1-SD-SR-030-JV
957701190
100 mm (res.: 7 mm)
DS1-HD-SR-010-JV
957701220
150 mm (res.: 7 mm)
DS1-HD-SR-015-JV
957701230
300 mm (res.: 7 mm)
DS1-HD-SR-030-JV
957701240
