ACCESSORIES
CS series – Cables & Connectors
The right connection for your photoelectric sensors
• M8 and M12, axial or radial female connectors
• Standard length cables: 3, 5, 7, 10, 15 or 25 m
• 3, 4, 5 or 8 poles
• Shielded or unshielded models
• P.U.R. coated models for use in harsh environments
• P.V.C. coated models for standard use
• Standard M12 4 pole non-cabled connectors
CS
Connectors
M8 axial or radial(90°) 3 poles
M12 axial or radial(90°) 3 poles
M8 axial or radial(90°) 4 poles
M12 axial or radial(90°) 4 poles
M12 axial 5 poles
M12 axial 8 poles
Cable lenghts
3, 5, 7, 10, 15, 25 m
Conductor diameter
42 x 0.10 mm - 0.35 mm≈ (m12 3-pole)
32 x 0.10 mm - 0.25 mm≈ (m12 4-pole)
32 x 0.10 mm - 0.25 mm≈ (m8 4-pole)
Conductor material
annealed non-tinned electrolytic copper
Flammability class
CEI 20-22, IEC 332/3
flame-retardant and non-propagate
Housing material
P.U.R., P.V.C.
Mechanical protection
IP67, with locked ring
