COMPACT SENSORS
-Processing and Packaging machinery
-Conveyor lines, material handling
-Automotive assembling lines
-Automated warehousing
APPLICATIONS
S90
Extended range of compact photoelectric sensors in a metal housing
• Background suppression and polarized
retroreflective
• Class 1 LASER models for long distance detection
• Contrast and UV Luminescence sensors
• Industrial IP67 metal housing
• Standard 4-wire NO-NC NPN or PNP output
S90
Through beam
0…20 m
0…60 m (class 1 LASER)
Polarized retroreflective
0…3,2 m (coaxial)
0,1…6,5 m
0,1…20 m (class 1 LASER)
Retroreflective for transparent (on R2 reflector)
0…1,7 m (coaxial)
Diffuse proximity
short 0,01...1 m
long 0,05...2 m
0...600 mm (class 1 LASER)
Background suppression
70...200 mm
50...100 mm (class 1 LASER)
Foreground suppression
70...200 mm
Luminescence
0...40 mm
Contrast
19 ± 2 mm
Power supply
Vdc
10…30 V
Vac
Vac/dc
Output
PNP
•
NPN
•
NPN/PNP
relay
other
Connection
cable
connector
•
pig-tail
Approximate dimensions (mm)
15x50x41
Housing material
Zama
Mechanical protection
IP67
