FIBER OPTIC SENSORS
OF/OFA series
Complete range of optic fibers: universal or advanced models
• Flexible models
• High temperature models (up to 125degC)
• Fiber array with parallel beams for proximity or
through beam detection
• Fixed focus proximity with axial, radial or lateral optics
• Proximity with 90° optics self-contained
• Focusing, collimating and deviating lenses
OF/OFA
Through beam
Mechanical characteristics, length, diameter of the optic fiber, as well as the switching frequencies,
light emitted and resolution of the optic fiber amplifier, affect the operating distances. Refer to the
manuals to find the proper operating distance.
Diffuse proximity
Fixed focus
OF diameter
M3, M4, M6
OFA number of emitted beams
1, 16, 32
Cable lenghts
1, 2 m
Operating temperature
-40…+60 °C (OF)
-40…125 °C (OF-…-HT)
-30…+70 °C (OFA)
Core material
PMMA plastic
Sheath material
PE plastic
Terminal material
Nickel-plated brass (OF),
Stainless steel, Aluminium, ABS (OFA)
Mechanical protection
IP67
