COMPACT SENSORS
-Automatic machines
-Packaging lines
-Transportation lines
-Automatic warehouses
APPLICATIONS
S6
Multivoltage 50x50 mm compact sensors series
• 50x50 mm compact dimensions
• Free voltage Vac/Vdc models with relay output
• 10-30 Vdc model with transistor output
• Standard cable or M12 4-pole connection
S6
Through beam
0…20 m
Retroreflective (on R2 reflector)
0,1…6 m (on R2 reflector)
Polarized retroreflective
0,1…5 m (on R2 reflector)
Diffuse proximity
10…900 mm
10…2000 mm
Background suppression
30…100 mm
30…250 mm
100…500 mm
Power supply
Vdc
10…30 V
Vac
Vac/dc
15…264 Vac/Vdc
Output
PNP
•
NPN
•
NPN/PNP
•
relay
•
other
Connection
cable
•
connector
•
pig-tail
Approximate dimensions (mm)
18x50x50
Housing material
ABS
Mechanical protection
IP65
