COMPACT SENSORS
-Processing and Packaging machinery
-Conveyor lines, material handling
APPLICATIONS
S62
The most complete universal sensor
in a compact 50x50 mm housing
• Sensors with red, infrared LED or LASER emission
• Background suppression from 3 cm to 2 m
• Polarized retroreflective up to 20 m
• Multivoltage 24-240Vac/24-60Vdc with Relay output
• NPN/PNP output NO-NC configuration
S62
Through beam
0…25 m
Retroreflective (on R2 reflector)
0,1…13 m
Polarized retroreflective
0,1…8 m
0,3…20 m (class 2 LASER)
Diffuse proximity
short 0…900 mm, long 0...2000 mm
0…900 mm (class 2 LASER)
Background suppression
short 30…300 mm
medium 60…600 mm
long 60…1200 mm
very long 200...2000 mm
short LASER 30…150 mm (class 2 LASER)
long LASER 50…350 mm (class 2 LASER)
Power supply
Vdc
10…30 V
Vac
Vac/dc
24/240 Vac/24…60 Vdc
Output
PNP
•
NPN
•
NPN/PNP
•
relay
•
other
Connection
cable
•
connector
•
pig-tail
Approximate dimensions (mm)
18x50x50
Housing material
ABS
Mechanical protection
IP67
