Optic function
EMISSION
CONNECTION
OUTPUT
MODEL
ORDER No.
Narrow beam diffuse proximity
LED
2 m Cable
PNP - LIGHT
S3Z-PR-2-C01-PL 95B010040
M8 Connector
PNP - LIGHT
S3Z-PR-5-C01-PL 95B010050
2 m Cable
PNP - DARK
S3Z-PR-2-C01-PD 95B010060
M8 Connector
PNP - DARK
S3Z-PR-5-C01-PD 95B010070
2 m Cable
NPN - LIGHT
S3Z-PR-2-C01-NL 95B010200
M8 Connector
NPN - LIGHT
S3Z-PR-5-C01-NL 95B010210
2 m Cable
NPN - DARK
S3Z-PR-2-C01-ND 95B010220
M8 Connector
NPN - DARK
S3Z-PR-5-C01-ND 95B010230
Long diffuse proximity
LED
2 m Cable
PNP - LIGHT
S3Z-PR-2-C11-PL 95B010001
M8 Connector
PNP - LIGHT
S3Z-PR-5-C11-PL 95B010011
2 m Cable
PNP - DARK
S3Z-PR-2-C11-PD 95B010021
M8 Connector
PNP - DARK
S3Z-PR-5-C11-PD 95B010031
2 m Cable
NPN - LIGHT
S3Z-PR-2-C11-NL 95B010161
M8 Connector
NPN - LIGHT
S3Z-PR-5-C11-NL 95B010171
2 m Cable
NPN - DARK
S3Z-PR-2-C11-ND 95B010181
M8 Connector
NPN - DARK
S3Z-PR-5-C11-ND 95B010191
Polarized retroreflective
LED
2 m Cable
PNP - LIGHT
S3Z-PR-2-B01-PL 95B010081
M8 Connector
PNP - LIGHT
S3Z-PR-5-B01-PL 95B010091
2 m Cable
PNP - DARK
S3Z-PR-2-B01-PD 95B010101
M8 Connector
PNP - DARK
S3Z-PR-5-B01-PD 95B010111
2 m Cable
NPN - LIGHT
S3Z-PR-2-B01-NL 95B010241
M8 Connector
NPN - LIGHT
S3Z-PR-5-B01-NL 95B010251
2 m Cable
NPN - DARK
S3Z-PR-2-B01-ND 95B010261
M8 Connector
NPN - DARK
S3Z-PR-5-B01-ND 95B010271
LASER
2 m Cable
PNP - DARK/LIGHT S3Z-PH-2-B01-PP 95B010440
M8 Connector
PNP - DARK/LIGHT S3Z-PH-5-B01-PP 95B010460
2 m Cable
NPN - DARK/LIGHT S3Z-PH-2-B01-NN 95B010450
M8 Connector
NPN - DARK/LIGHT S3Z-PH-5-B01-NN 95B010470
Through beam
LED
2 m Cable
PNP - LIGHT
S3Z-PR-2-FG01-PL 95B010121
M8 Connector
PNP - LIGHT
S3Z-PR-5-FG01-PL 95B010131
2 m Cable
PNP - DARK
S3Z-PR-2-FG01-PD 95B010141
M8 Connector
PNP - DARK
S3Z-PR-5-FG01-PD 95B010151
2 m Cable
NPN - LIGHT
S3Z-PR-2-FG01-NL 95B010281
M8 Connector
NPN - LIGHT
S3Z-PR-5-FG01-NL 95B010291
2 m Cable
NPN - DARK
S3Z-PR-2-FG01-ND 95B010301
M8 Connector
NPN - DARK
S3Z-PR-5-FG01-ND 95B010311
LASER
2 m Cable
PNP - DARK/LIGHT S3Z-PH-2-FG01-PP 95B010520
M8 Connector
PNP - DARK/LIGHT S3Z-PH-5-FG01-PP 95B010540
2 m Cable
NPN - DARK/LIGHT S3Z-PH-2-FG01-NN 95B010530
M8 Connector
NPN - DARK/LIGHT S3Z-PH-5-FG01-NN 95B010550
Background suppression
LED
2 m Cable
PNP - LIGHT
S3Z-PR-2-M01-PL 95B010330
M8 Connector
PNP - LIGHT
S3Z-PR-5-M01-PL 95B010350
2 m Cable
NPN - LIGHT
S3Z-PR-2-M01-NL 95B010320
M8 Connector
NPN - LIGHT
S3Z-PR-5-M01-NL 95B010340
LASER
2 m Cable
PNP - DARK/LIGHT S3Z-PH-2-M01-PP 95B010480
M8 Connector
PNP - DARK/LIGHT S3Z-PH-5-M01-PP 95B010500
2 m Cable
NPN - DARK/LIGHT S3Z-PH-2-M01-NN 95B010490
M8 Connector
NPN - DARK/LIGHT S3Z-PH-5-M01-NN 95B010510
Polarized retroreflective
for transparent
LED
2 m Cable
NPN - DARK
S3Z-PR-2-T51-ND 95B010390
2 m Cable
PNP - DARK
S3Z-PR-2-T51-PD 95B010380
M8 Connector
NPN - DARK
S3Z-PR-5-T51-ND 95B010370
M8 Connector
PNP - DARK
S3Z-PR-5-T51-PD 95B010360
LIGHT= N.O.
DARK= N.C.
