Lens shields
The LENS SHIELD accessory for safety light curtains is composed of a PMMA Altuglas plate that can be mounted on the
front glass of the safety light, ensuring an effective protection against dust, chips and incandescent drops deriving from
material working near the safety light curtain.
MODEL
DESCRIPTION
ORDER NUMBER
SG -LS 150
Lens shield 150 mm
95ASE 1450
SG -LS 300
Lens shield 300 mm
95ASE 1460
SG -LS 450
Lens shield 450 mm
95ASE 1470
SG -LS 600
Lens shield 600 mm
95ASE 1480
SG -LS 750
Lens shield 750 mm
95ASE 1490
SG -LS 900
Lens shield 900 mm
95ASE 1500
SG -LS 1050
Lens shield 1050 mm
95ASE 1510
SG -LS 1200
Lens shield 1200 mm
95ASE 1520
SG -LS 1350
Lens shield 1350 mm
95ASE 1530
SG -LS 1500
Lens shield 1500 mm
95ASE 1540
SG -LS 1650
Lens shield 1650 mm
95ASE 1550
SG -LS 1800
Lens shield 1800 mm
95ASE 1560
SG -LS 2
Lens shield 2 beams 500 mm
95ASE 1570
SG -LS 3
Lens shield 3 beams 800 mm
95ASE 1580
SG -LS 4-900
Lens shield 4 beams 900 mm
95ASE 1590
SG -LS 4-120
Lens shield 4 beams 1200 mm
95ASE 1600
SG -LS-MC 4
Elastic fastner for lens shield (kit 4pcs.)
95ASE 1810
COMPATIBILITY
SG-LS xxxx
SG2 BASE
SG2 EXTENDED
SG4 BASE
SG-LS 2
SG-LS 3
SG-LS 4-900
SG-LS 4-120
SG BODY COMPACT
NOTES
1) Each package contains the necessary to protect a single unit (emitter or receiver). To protect both elements of a couple, order two pieces
2) Five plates are supplied in the package for replacements
3) The length indicated in the descritpion is the height of the light curtains that can be used with the lens shield, for the actual dimension, refer to the technical datasheet.
