-Processing and Packaging machinery
-Assembling and Conveyor lines
APPLICATIONS
TUBULAR SENSORS
S15
Plastic and stainless steel tubular M18 photoelectric sensors
every environment
• Short case models for cost and space savings
• Plastic and stainless steel case with IP69K protection
• All optic functions at optimal operating distances
• Models with fixed settings or adjustment trimmer
• Cable, M12 connector and pig-tail models
S15
Through beam
0…20 m
Retroreflective (on R2 reflector)
0,1…5 m
Polarized retroreflective
0,1…4 m
Retroreflective for transparent (on R2 reflector)
0,1…0,8 m
Diffuse proximity
short distance 0…100 mm
medium distance 0…350 mm
long distance 1 m
Fixed focus
0…50 mm
Background suppression
40…120 mm
Power supply
Vdc
10…30 V
Vac
Vac/dc
Output
PNP
•
NPN
•
NPN/PNP
relay
other
Connection
cable
•
connector
•
pig-tail
•
Approximate dimensions (mm)
M18x44/48
Housing material
ABS, INOX AISI 316L
Mechanical protection
IP65 - IP67 - IP69K
(*) Stainless steel models.
ATEX
II
3DG
IP69K
(*)
