22
-Processing and Packaging machinery
-Conveyor lines, material handling
-Ceramics intralogistics
-Automated warehousing
APPLICATIONS
TUBULAR SENSORS
S50/S51
Extended range of standard “One for All” photoelectric tubular M18 sensors
• All optic functions and LASER models
• M18 flat plastic with universal mounting
• Available in M18 metal housing
• Axial or radial optics, cable or connector
• Standard 4-wire NO-NC NPN or PNP output
S50/S51
Through beam
0…20 m
0…60 m (class 1 LASER) (S50)
Retroreflective (on R2 reflector)
0,1…4 m
Polarized retroreflective
0,1…4 m (S50) 0,1…3 m (S51)
0,1…16 m (class 1 LASER) (S50)
Retroreflective for transparent (on R2 reflector)
0,1…1,3 m (S50)
Diffuse proximity
short distance 0...100 mm
medium distance 0...400 mm (S50) 0...450 mm (S51)
long distance 0...700 mm
long distance Laser 0...350 mm
Fixed focus
100 mm (S50)
Background suppression
50…100 mm (S50)
Through beam with fiber optic
0…100 mm (S50)
Diffuse proximity with fiber optic
0…30 mm (S50)
Contrast sensor
10 ±2 mm
Luminescence sensor
0…20 mm
Power supply
Vdc
10…30 V
Vac
Vac/dc
Output
PNP
•
NPN
•
NPN/PNP
relay
other
Connection
cable
•
connector
•
pig-tail
Approximate dimensions (mm)
M18x 55/68
Housing material
PBT, nickel plated brass
Mechanical protection
IP67
(*)
(*) Axial models.
ATEX
II
3DG
