SELECTION CHART
UNIVERSAL PHOTOELECTRIC SE
TUBULAR
MINIATURE
Max operating distance
S15
S50/S51
SMall
S40
S41
Through beam
0…20 m
0…60 m
0…2 m
0,1…6 m
Retroreflective
0,1…5 m
0,1…4 m
0,05…1,5 m
Polarized retroreflective
0,1…4 m
0,1...16 m
0,1…1 m
0,1…6 m
0,1…2,5 m
Retroreflective for transparent
0,1…0,8 m
0,1…1,3 m
100...700 mm 100...700 mm
Diffuse proximity
0…1 m
0…700 mm
5…300 mm
2…350 mm
Fixed focus
0…50 mm
100 mm
3…50 mm
110 mm
Background suppression
40…120 mm
50…100 mm
15…100 mm
Fiber optic
0…100mm (throughbeam)
0...30mm (diffuseproximity)
Contrast
10 ±2 mm
Luminescence
0…20 mm
Page
20
22
28
30
32
The table shows the maximum operating distance reached by different sensors models. Some measures indicate only the highest performances obtained by the corresponding sensor.
Other operating distance values might be available for the same series and some optic functions might be carried out through LED or LASER emission, reaching different distances. For
more specific information refer to the dedicated product page in this guide or download datasheets and manuals from our website (
)
