ACCESSORIES
DESCRIPTION
MODEL
ORDER NO.
Flexible Aluminium coupling Ø6 mm
FAC06-06
95B081300
Flexible Aluminium coupling Ø10 mm
FAC10-10
95B081310
Flexible standard plastic coupling Ø6 mm
FBC06-06
95B081320
Flexible standard plastic coupling Ø10 mm
FBC10-10
95B081330
Encoder reducing sleeve Ø15 - 6 mm
RS15-06
95B081340
Encoder reducing sleeve Ø15 - 8 mm
RS15-08
95B081350
Encoder reducing sleeve Ø15 - 10 mm
RS15-10
95B081360
Encoder reducing sleeve Ø15 - 11 mm
RS15-11
95B081370
Encoder reducing sleeve Ø15 - 12 mm
RS15-12
95B081380
Encoder reducing sleeve Ø15 - 9.52 mm (3/8")
RS15-3/8
95B081390
Ø58 Encoder fixing clamps (3 kits)
ST-58-KIT
95B081400
Ø58 Encoder mounting bell
ST-58-BELL
95B081410
Ø58 Encoder mounting L-bracket
ST-58-BRKT
95B081420
Ø58 Encoder mounting square flange
ST-58-FLNG
95B081430
Absolute encoder conn. ccw M23 12-poles with 5m cable
CN-M23A-12P-05
95B081290
Absolute encoder conn. ccw M23 12-poles with 10m cable
CN-M23A-12P-10
95B081450
Absolute encoder conn. ccw M23 12-poles without cable
M23A-12P-00
95B081470
Metal M12 8-poles female conn. with 5m cable
CN-M12-08P-05
95B081230
Metal M12 8-poles female conn. with 10m cable
CN-M12-08P-10
95B081240
Metal M12 8-poles female connector without cable
CN-M12-08P-00
UL Plastic M12 8-poles female conn. with 3m cable
CS-A1-06-U-03
9
UL Plastic M12 8-poles female conn. with 5m cable
CS-A1-06-U-05
9
UL Plastic M12 8-poles female conn. with 10m cable
CS-A1-06-U-10
95ASE1190
UL Plastic M12 8-poles female conn. with 15m cable
CS-A1-06-U-15
95ASE1200
UL Plastic M12 8-poles female conn. with 25m cable
CS-A1-06-U-25
95ASE1210
UL Plastic M12 8-poles female conn. with 50m cable
95A252700
UL Plastic M12 8-poles female connector without cable
95ACC2550
FAC06-06
(L22/D19/d6 mm)
FAC10-10
(L24/D25/d10 mm)
ST58-KIT
ST-58-FLNG
RS15-xx
(int. Ø as
description)
FBC06-06
(L29/D22/d
FBC10-10
(L29/D22/d10 mm)
ST-58-BELL
ST-58-BRKT
ROTACOD
PAN KUPPLUNGEN/GIUNTI ELASTICI
Mod.
L
D
d
d1
PAN 6
22
19
6
6
PAN 8
24
25
8
8
PAN 10
24
PAN 12
24
PGF KUPPLUNGEN/GIUNTI ELASTICI
Mod.
L
D
d
d1
PGF 6
29
22
6
6
PGF 8
29
22
8
8
PGF 10
29
22
10
10
Kit LKM-386 Konfektion von 3
Servoklammern mit Schrauben und
Muttern.
KIT LKM-386 è completo di tre graffe di
fissaggio, viti e dadi.
E
BR1-12
Ø 12mm h7
BR1-10
Ø 10mm h7
BR1-9.52
Ø 9.52mm h7
BR1-8
Ø 8mm h7
BR1-6
Ø 6mm h7
BR1 REDUZIERHÜLSEN/BOCCOLE DI RIDUZIONE
•
ROTACOD
O
PAN KUPPLUNGEN/GIUNTI ELASTICI
Mod.
L
D
d
d1
PAN 6
22
19
6
6
PAN 8
24
25
8
8
PAN 10
24
25
10
10
PAN 12
24
25
12
12
PGF KUPPLUNGEN/GIUNTI ELASTICI
Mod.
L
D
d
d1
PGF 6
29
PGF 8
29
PGF 10
29
22
10
10
MESSRÄDER/RUOTE METRICHE
Type/Modello
Umfang/Circ.
Oberfläche/Superficie
Ø d
L
RM200GZ
200 mm
Gummi/
Gomma
6 mm
12 mm
RM500G
500 mm
Gummi (glatt)/
Gomma (liscia)
8 mm
24 mm
RM500Z
500 mm
Metall/
Metallo
8 mm
24 mm
Kit LKM-386 Konfektion von 3
Servoklammern mit Schrauben und
Muttern.
KIT LKM-386 è completo di tre graffe di
fissaggio, viti e dadi.
NE
BR1-12
Ø 12mm h7
BR1-10
Ø 10mm h7
BR1-9.52
Ø 9.52mm h7
BR1-8
Ø 8mm h7
BR1-6
Ø 6mm h7
BR1 REDUZIERHÜLSEN/BOCCOLE DI RIDUZIONE
R
TACOD
Zubehör
•
Access
MONTAGEGLOCKEN/BEFESTIGUNGSBÜGEL
CAMPANE DI FISSAGGIO/STAFFE
Für Serien I58S, I65 und Ax58S
Usare con I58S, I65 e Ax58S
Für Serien I58S, I65 und Ax58S
Usare con I58S, I65 e Ax58S
ww
ROTAPULS
•
ROTACOD
Zübehör
•
Accessori
KUPPLUNGEN
GIUNTI ELASTICI
SERVOKLAMMERN
GRAFFE DI FISSAGGIO
MESSRÄDER
RUOTE METRICHE
PAN KUPPLUNGEN/GIUNTI ELASTICI
Mod.
L
D
d
d1
PAN 6
22
19
6
6
PAN 8
24
25
8
8
PAN 10
24
25
10
10
PAN 12
24
25
12
12
PGF KUPPLUNGEN/GIUNTI ELASTICI
Mod.
L
D
d
d1
PGF 6
29
22
6
6
PGF 8
29
22
8
8
PGF 10
29
22
10
10
MESSRÄDER/RUOTE METRICHE
Type/Modello
Umfang/Circ.
Oberfläche/Superficie
Ø d
L
RM200GZ
200 mm
Gummi/
Gomma
6 mm
12 mm
Kit LKM-386 Konfektion von 3
Servoklammern mit Schrauben und
Muttern.
KIT LKM-386 è completo di tre graffe di
fissaggio, viti e dadi.
REDUZIERHÜLSEN
BOCCOLE DI RIDUZIONE
BR1-12
Ø 12mm h7
BR1-10
Ø 10mm h7
BR1-9.52
Ø 9.52mm h7
BR1-8
Ø 8mm h7
BR1-6
Ø 6mm h7
BR1 REDUZIERHÜLSEN/BOCCOLE DI RIDUZIONE
s. Montagehinweise Seite 78
Vedi istruzioni di montaggio pag. 78
ROTAPULS
•
ROTACOD
Zübehör
•
Accessori
KUPPLUNGEN
GIUNTI ELASTICI
SERVOKLAMMERN
GRAFFE DI FISSAGGIO
MESSRÄDER
RUOTE METRICHE
PA
Mod.
PAN 6
PAN 8
PAN 10
PAN 12
P
Mod.
PGF 6
PGF 8
PGF 10
MESSRÄDER/RUOTE METRICH
Type/Modello
Umfang/Circ.
Oberfläche/Sup
RM200GZ
200 mm
Gummi/
Gom
RM500G
500 mm
Gummi (glatt)/
Gom
RM500Z
500 mm
Metall/
Metall
REDUZIERHÜLSEN
BOCCOLE DI RIDUZIONE
BR
BR
BR
B
B
BR1 RED
s. Montagehinweise Seite 78
Vedi istruzioni di montaggio pag. 78
PULS
•
ROTACOD
Accessori
EN/BEFESTIGUNGSBÜGEL
DI FISSAGGIO/STAFFE
Für Serien I58S, I65 und Ax58S
Usare con I58S, I65 e Ax58S
Für Serien I58S, I65 und Ax58S
Usare con I58S, I65 e Ax58S
LKM-531
LKM-391
ROTAPULS
•
ROTACOD
Zubehör
•
Accessori
MONTAGEGLOCKEN/BEFESTIGUNGSBÜGEL
CAMPANE DI FISSAGGIO/STAFFE
Für Serien I58S, I65 und Ax58S
Usare con I58S, I65 e Ax58S
Für Serien I58S, I65 und Ax58S
Usare con I58S, I65 e Ax58S
ADAPTERFLANSCH
FLANGE DI ADATTAMENTO
LKM-531
LKM-391
